PRODUCT PORTFOLIO

Star product
CGS Oris Real Substrate Proof

A fully colour-accurate digital proofing system for packaging, says Simon Eccles

How does it work?
There are two main elements to the sys-
tem, software and printer-ink combination.
The Flex Pack software handles the simula-
tion of print processes and also rips and
drives the printer. CGS says this includes
iterative 4D colour management and spot
colour management, with the ability to
simulate flexo, gravure or other analogue
and digital processes.
It’s Windows based and doesn’t need a
high-power server. It can be accessed
remotely by any web browser with permis-
sions.
The standard printer is the Mutoh
628MP, a version of the low-cost standard
VJ 628 that uses multi-resin inks instead of
the standard eco solvent type. The multi-
What does it do? Specifications essentially an improved version of the Flex resin ink is broadly similar to HP’s better-
This is a complete software, printer and Pack + Mutoh system introduced in 2021. known Latex inks, and likewise is
ink solution to print contract proofs onto a Platform: Windows This used the same software and printer, water-based with the pigments carried by
wide range of flexible and rigid packaging but with Mutoh’s own resin inks that have heat-activated resins. Müller says that the
substrates, developed by German proofing Printer: Mutoh light cyan and light magenta, rather than printer resolution is high enough to even
specialist CGS Oris. As the name says, 628MP (standard), the new set’s gamut-extending orange and
these are the actual production substrates Mutoh 1628MH green, and that only hit about 90% of print halftones from 1-bit TIFF files, though
(optional, pur-
rather than simulations, including flexible chased via Mutoh Pantone colours. he says even customers who said they
packaging and pouch materials, shrink channel) According to Heiner Müller, director of wanted this are mostly printing contone
films, in-mould label transfers, papers, packaging at CGS, the target markets are proofs.
folding boxboard and metallised board. Max media thick- primarily packaging design and pre-press
Even metal can be printed, which after ness: 1.3mm houses that want to output proofs and test He admits that the drying system means
coating can be baked. The standard system (628MP), 16mm dummies of new products. “The require- the printer is relatively slow – an A3 sheet
comprises CGS Oris Flex Pack proofing (1628MH) ment for physical mock-ups is much higher takes about 15 minutes, but the system can
software plus a Mutoh ValueJet 628MP in the UK than in Germany,” he says, put-
24in roll-fed printer (to which CGS has Max resolution: ting it down to the number of multination- be left to run unattended and the proofs are
exclusive sales rights) and the newly devel- 1,440dpi als that have UK offices. There are already dry when they emerge. The VJ 628 is a com-
oped XG resin inkset, that offers extended about 500 users of the earlier Mutoh-based pact printer and the inks are non-toxic and
gamuts to handle “almost 100%” of the Inks: CGS XR multi- CGS solution, and they can switch to the odourless, so the system could fit into a
Pantone colour set. The inks are CMYK resin new orange and green XG inks after clean-
plus orange, green and white. ing out the relevant channels. “Most work design office. The 24in media width allows
Alternatively a Mutoh 1628MH 64in Colours: CMYK plus with flexo printing,” says Müller, “but there B2-sized proofs or longer to be handled.
hybrid flatbed/roll printer can be used with orange, green and are some narrow-web labels, some offset The alternate Mutoh 1628MH hybrid
the same inks; this is able to handle rigid white and some gravure.”
media up to 16mm thick: the 628MP can He says that many customers had previ- option has a 64in width and a much larger
handle smaller sheets but with a maximum Speed:About 15 ously used the now-obsolete Kodak footprint thanks to the flatbed table.
thickness of 1.4mm. minutes per A3 Approval XP4 laser pigment transfer based Raised-image effects such as embossing can
A2-plus digital proofing system, which was also be simulated as a second overprint pro-
When was it introduced and what are Price: From £34,000 highly regarded but very expensive, or the
the target markets? lower priced and quite widely used 2009 cess using high-build clear UV inks on the
In its latest ‘Real Substrate’ form it was Epson SP WT7900 24in inkjet-on-film Roland VersaUV LEF (2)-200/300 or
introduced on 1 July. However, this is proofer which is no longer made. LEC2-330s baby flatbed inkjets.
This is essentially an improved version of the Flex Pack + Mutoh system introduced in 2021.
