PRODUCT PORTFOLIO

Star product
CGS Oris Real Substrate Proof

A fully colour-accurate digital proofing system for packaging, says Simon Eccles
How does it work?
There are two main elements to the system,
software and printer-ink combination. The
Flex Pack software handles the simulation
of print processes and also rips and drives
the printer. CGS says this includes iterative
4D colour management and spot colour
management, with the ability to simulate
flexo, gravure or other analogue and digital
processes.
It’s Windows based and doesn’t need a
high-power server. It can be accessed
remotely by any web browser with permis-
sions. The standard printer is the Mutoh
628MP, a version of the low-cost standard
VJ 628 that uses multi-resin inks instead of
the standard eco solvent type. The multi-
resin ink is broadly similar to HP’s better-
known Latex inks, and likewise is
What does it do? essentially an improved version of the Flex water-based with the pigments carried by
This is a complete software, printer and Specifications Pack + Mutoh system introduced in 2021. heat-activated resins. Müller says that the
ink solution to print contract proofs onto Platform This used the same software and printer,
a wide range of flexible and rigid packag- Windows but with Mutoh’s own resin inks that have printer resolution is high enough to even
ing substrates, developed by German light cyan and light magenta, rather than print halftones from 1-bit TIFF files, though
proofing specialist CGS Oris. As the Printer Mutoh 628MP the new set’s gamut-extending orange and he says even customers who said they
name says, these are the actual produc- (standard), Mutoh green, and that only hit about 90% of
tion substrates rather than simulations, 1628MH (optional, pur- Pantone colours. wanted this are mostly printing contone
including flexible packaging and pouch chased via Mutoh chan- According to Heiner Müller, director of proofs.
materials, shrink films, in-mould label nel) packaging at CGS, the target markets are He admits that the drying system means the
transfers, papers, folding boxboard and primarily packaging design and pre-press printer is relatively slow – an A3 sheet takes
metallised board. Even metal can be Max media thickness houses that want to output proofs and test
printed, which after coating can be 1.3mm (628MP), 16mm dummies of new products. “The require- about 15 minutes, but the system can be left
baked. The standard system comprises (1628MH) ment for physical mock-ups is much higher to run unattended and the proofs are dry
CGS Oris Flex Pack proofing software in the UK than in Germany,” he says, put- when they emerge. The VJ 628 is a compact
plus a Mutoh ValueJet 628MP 24in roll- Max resolution 1,440dpi ting it down to the number of multination- printer and the inks are non-toxic and
fed printer (to which CGS has exclusive als that have UK offices. There are already
sales rights) and the newly developed XG Inks CGS XR multi-resin odourless, so the system could fit into a
resin inkset, that offers extended gamuts about 500 users of the earlier Mutoh-based design office. The 24in media width allows
CGS solution, and they can switch to the
to handle “almost 100%” of the Pantone Colours CMYK plus B2-sized proofs or longer to be handled.The
colour set. The inks are CMYK plus orange, green and white new orange and green XG inks after clean-
orange, green and white. Alternatively a ing out the relevant channels. “Most work alternate Mutoh 1628MH hybrid option
Mutoh 1628MH 64in hybrid flatbed/roll Speed About 15 minutes with flexo printing,” says Müller, “but there has a 64in width and a much larger foot-
printer can be used with the same inks; per A3 are some narrow-web labels, some offset print thanks to the flatbed table. Raised-
this is able to handle rigid media up to and some gravure.” image effects such as embossing can also be
16mm thick: the 628MP can handle Price From £34,000 He says that many customers had previ-
smaller sheets but with a maximum 210x297mm/600x400mm ously used the now-obsolete Kodak simulated as a second overprint process
thickness of 1.4mm. Approval XP4 laser pigment transfer based using high-build clear UV inks on the
Feed capacity 30mm A2-plus digital proofing system, which was Roland VersaUV LEF (2)-200/300 or
When was it introduced and what highly regarded but very expensive, or the
are the target markets? lower priced and quite widely used 2009 LEC2-330s baby flatbed inkjets. Cold foil
In its latest ‘Real Substrate’ form it was Epson SP WT7900 24in inkjet-on-film can be applied by part-curing the UV ink to
introduced on 1 July. However, this is proofer which is no longer made. leave it sticky.
“This is essentially an improved version of the Flex Pack + Mutoh system introduced in 2021.”
